HELUKABEL 22237 TOPFLEX EMV-UV-2YSLCYK-J black 4 G 6 mm²
HELUKABEL 22237 TOPFLEX EMV-UV-2YSLCYK-J black 4 G 6 mm²

HELUKABEL 22237 TOPFLEX EMV-UV-2YSLCYK-J black 4 G 6 mm² (HELUKABEL 22237)

Marka : HELUKABEL
Fiyat : €18,72(KDV Dahil)
TL Fiyat : ₺912,21(KDV Dahil)

TEYİDLİ SİPARİŞ

Teslim Süresi : 18 Gün
Favorilere Ekle
İstek Listeme Ekle
Karşılaştır
Fiyat Düşünce Haber Ver
Gelince Haber Ver
Tavsiye Et
Yorum Yaz
Satıcıya Soru Sor

HELUKABEL 22237 TOPFLEX EMV-UV-2YSLCYK-J black 4 G 6 mm²

Part no. 22237

Item Details

Part no.
22237
Item description
TOPFLEX®-EMV-UV-2YSLCYK-J black 4 G 6 mm²
AWG (approx.)
10
Outer Ø mm (approx.)
15.3
Cu factor per km
320.0
Weight kg/km (approx.)
457.0
Copper base in EUR / 100 kg
150
Metres per Packaging Unit
500, 1000
Cut-to-length service available
yes
EAN / GTIN
4060892149740
Customs tariff number
85444995

Technical Data



Motor connection cable for frequency converters in alignment with DIN VDE 0250
Temperature range flexible -5°C to +70°C
fixed -40°C to +70°C
Nominal voltage AC U0/U 600/1000 V
Max. permissible operating voltage alternating current (AC) conductor/earth 700 V
three-phase alternating current (AC) conductor/conductor 1200 V
direct current (DC) conductor/earth 900 V
direct current (DC) conductor/conductor 1800 V
Test voltage core/core 4000 V
Mutual capacitance see datasheet
Coupling resistance see datasheet
Minimum bending radius flexible <12 mm: 10x Outer-ø
flexible >12 mm: 15x Outer-ø
fixed 4x Outer-ø
