HK Instruments DPT7000-R8-AZ – Hava İçin Fark Basınç Sensörü Yüksek ölçüm aralıklı, otomatik sıfırlama (AutoZero) özellikli diferansiyel basınç transmitteri Temel Teknik Özellikler Özellik Değer / Açıklama Ölçüm Ortamı Hava ve diğer nötr, yanıcı olmayan gazlar Seçilebilir Ölçüm Aralıkları 0…1.000 Pa, 0…1.500 Pa, 0…2.000 Pa, 0…2.500 Pa, 0…3.000 Pa, 0…4.000 Pa, 0…5.000 Pa, 0…7.000 Pa Otomatik Sıfırlama (AutoZero) Sensör belirli aralıklarla kendini otomatik sıfırlayarak uzun dönemli ölçüm kararlılığı sağlar Çıkış Sinyali 0–10 V DC veya 4–20 mA (kullanıcı tarafından seçilebilir) Besleme Gerilimi 24 V DC / 24 V AC Tipik Uygulamalar HVAC sistemleri, havalandırma kanalı basınç izleme, fan ve filtre kontrolü, temiz oda ve endüstriyel proses basınç ölçümleri Montaj Duvar veya kanal montajına uygun kompakt muhafaza Koruma Sınıfı IP54 (tipik, montaj koşullarına bağlı) Özet DPT7000-R8-AZ, hava ve nötr gazlarda 7.000 Pa’ya kadar geniş ölçüm aralıklarında hassas fark basınç ölçümü sağlar. Entegre AutoZero özelliği, sensörün düzenli aralıklarla kendini otomatik olarak kalibre etmesini sağlayarak ölçümlerin uzun süre stabil ve doğru kalmasına yardımcı olur. 0–10 V DC veya 4–20 mA çıkış seçenekleri ve 24 V DC/AC besleme ile yüksek aralıklı HVAC, havalandırma ve endüstriyel basınç izleme uygulamaları için ideal bir çözümdür.
HK Instruments DPT7000-R8-AZ – Differential Pressure Sensor for Air High-range differential pressure transmitter with AutoZero (automatic zeroing) function Key Technical Specifications Feature Value / Description Medium Air and other neutral, non-flammable gases Selectable Measuring Ranges 0…1,000 Pa, 0…1,500 Pa, 0…2,000 Pa, 0…2,500 Pa, 0…3,000 Pa, 0…4,000 Pa, 0…5,000 Pa, 0…7,000 Pa AutoZero Function Automatic self-zeroing ensures long-term measurement stability and removes the need for manual zero adjustment Output Signal 0–10 V DC or 4–20 mA (user-selectable) Supply Voltage 24 V DC / 24 V AC Typical Applications HVAC systems, ventilation duct pressure monitoring, fan and filter control, clean-room and industrial process pressure measurement Mounting Compact enclosure for wall or duct installation Protection Class IP54 (typical, depending on installation) Summary The DPT7000-R8-AZ provides accurate differential pressure measurement for air and neutral gases up to 7,000 Pa. Its integrated AutoZero feature automatically calibrates the sensor at set intervals, guaranteeing stable and precise readings over time. With dual output options (0–10 V DC or 4–20 mA) and a 24 V DC/AC power supply, it is ideal for high-range HVAC, ventilation, and industrial air-pressure monitoring and control.
HK Instruments DPT7000-R8-AZ – Differential Pressure Sensor for Air High-range differential pressure transmitter with AutoZero (automatic zeroing) function Key Technical Specifications Feature Value / Description Medium Air and other neutral, non-flammable gases Selectable Measuring Ranges 0…1,000 Pa, 0…1,500 Pa, 0…2,000 Pa, 0…2,500 Pa, 0…3,000 Pa, 0…4,000 Pa, 0…5,000 Pa, 0…7,000 Pa AutoZero Function Automatic self-zeroing ensures long-term measurement stability and removes the need for manual zero adjustment Output Signal 0–10 V DC or 4–20 mA (user-selectable) Supply Voltage 24 V DC / 24 V AC Typical Applications HVAC systems, ventilation duct pressure monitoring, fan and filter control, clean-room and industrial process pressure measurement Mounting Compact enclosure for wall or duct installation Protection Class IP54 (typical, depending on installation) Summary The DPT7000-R8-AZ provides accurate differential pressure measurement for air and neutral gases up to 7,000 Pa. Its integrated AutoZero feature automatically calibrates the sensor at set intervals, guaranteeing stable and precise readings over time. With dual output options (0–10 V DC or 4–20 mA) and a 24 V DC/AC power supply, it is ideal for high-range HVAC, ventilation, and industrial air-pressure monitoring and control.
HK Instruments DPT7000-R8-AZ – Differential Pressure Sensor for Air High-range differential pressure transmitter with AutoZero (automatic zeroing) function Key Technical Specifications Feature Value / Description Medium Air and other neutral, non-flammable gases Selectable Measuring Ranges 0…1,000 Pa, 0…1,500 Pa, 0…2,000 Pa, 0…2,500 Pa, 0…3,000 Pa, 0…4,000 Pa, 0…5,000 Pa, 0…7,000 Pa AutoZero Function Automatic self-zeroing ensures long-term measurement stability and removes the need for manual zero adjustment Output Signal 0–10 V DC or 4–20 mA (user-selectable) Supply Voltage 24 V DC / 24 V AC Typical Applications HVAC systems, ventilation duct pressure monitoring, fan and filter control, clean-room and industrial process pressure measurement Mounting Compact enclosure for wall or duct installation Protection Class IP54 (typical, depending on installation) Summary The DPT7000-R8-AZ provides accurate differential pressure measurement for air and neutral gases up to 7,000 Pa. Its integrated AutoZero feature automatically calibrates the sensor at set intervals, guaranteeing stable and precise readings over time. With dual output options (0–10 V DC or 4–20 mA) and a 24 V DC/AC power supply, it is ideal for high-range HVAC, ventilation, and industrial air-pressure monitoring and control.
