Temel Özellikler Özellik Detay Ölçüm Prensibi Direnç Termometresi (RTD) Tasarım / Uygulama Metrik tip, kompakt sıcaklık probu, hızlı tepki süresi, hijyenik tasarım ve proses bağlantısı; boyunlu veya boyunsuz seçenek Kılıf / Koruma Tüpü (Thermowell) • Thermowell olmadan doğrudan kullanım • Thermowell ile uyumlu • T-bağlantılı veya dirsek tipi thermowell seçeneği Sensör Ucu / Prob Boru tipi, izole kablolu, esnek değil Dış Çap (Koruma Tüpü / Prob) 3,0 mm (0,12") veya 6,0 mm (0,24") Maks. Daldırma Boyu Talebe bağlı olarak 600 mm’ye (23,62") kadar Malzeme (Koruma Tüpü / Thermowell) Paslanmaz çelik 1.4404 (316L) Proses Bağlantısı (Hijyenik) • Konik sızdırmazlık sistemi G1/2" (metal) • ISO 2852 / DIN 32676 kelepçe bağlantısı • DIN 11851 vidalı boru bağlantısı • Varivent Uç Şekli Düz Yüzey Pürüzlülüğü (Ra) 0,4 µm (16 µin) veya 0,8 µm (32 µin) Çalışma Sıcaklık Aralığı –50 °C … +200 °C (–58 °F … +392 °F) Maks. Proses Basıncı (Statik) 20 °C’de 100 bar (1.450 psi) Doğruluk IEC 60751 Class A Tepki Süresi t₅₀ = 1 s, t₉₀ = 2 s Başlık Tipi / Transmitter Entegre değil (4…20 mA sinyal için harici transmitter) Sertifikalar 3-A Hijyenik Sertifika, Marine Approval, UL 3111-1 Özet Bu kompakt hijyenik RTD sıcaklık probu, gıda, içecek, ilaç ve denizcilik uygulamaları gibi hijyen gerektiren endüstriler için hızlı tepki ve yüksek hassasiyet sunar. 316L paslanmaz çelik gövdesi ile dayanıklı olup 100 bar’a kadar proses basıncına dayanabilir. Thermowell ile veya doğrudan kullanılabilir, farklı hijyenik bağlantı seçenekleri ile kurulumu kolaydır. Key Specifications Feature Detail Measuring Principle Resistance Temperature Detector (RTD) Design / Application Metric-style compact probe with fast response, hygienic design and process connections; available with or without neck Thermowell / Protection Tube • Direct use without thermowell • Compatible with separate thermowell • Optional Tee or elbow-type thermowell Insert / Probe Pipe version, isolated wires, non-flexible Outer Diameter (Protection Tube / Insert) 3.0 mm (0.12") or 6.0 mm (0.24") Maximum Immersion Length Up to 600 mm (23.62") on request Material (Protection Tube / Thermowell) Stainless steel 1.4404 (316L) Process Connection (Hygienic) • Conical sealing system G1/2" (metal) • Clamp connections ISO 2852 / DIN 32676 • Screwed pipe joint DIN 11851 • Varivent Tip Shape Straight Surface Roughness (Ra) 0.4 µm (16 µin) or 0.8 µm (32 µin) Operating Temperature Range –50 °C to +200 °C (–58 °F to +392 °F) Max. Process Pressure (Static) 100 bar (1,450 psi) at 20 °C Accuracy Class A according to IEC 60751 Response Time t₅₀ = 1 s, t₉₀ = 2 s Head Transmitter Not integrated (requires external 4…20 mA transmitter) Certifications 3-A Sanitary, Marine Approval, UL 3111-1 Summary This compact hygienic RTD sensor delivers fast, precise temperature measurement for sanitary and industrial applications. Built from 316L stainless steel for high durability, it withstands pressures up to 100 bar and operates from –50 °C to +200 °C. The probe can be used directly or with a thermowell and offers multiple hygienic process connection options for easy installation in food, beverage, pharmaceutical, and marine environments.
Key Specifications Feature Detail Measuring Principle Resistance Temperature Detector (RTD) Design / Application Metric-style compact probe with fast response, hygienic design and process connections; available with or without neck Thermowell / Protection Tube • Direct use without thermowell • Compatible with separate thermowell • Optional Tee or elbow-type thermowell Insert / Probe Pipe version, isolated wires, non-flexible Outer Diameter (Protection Tube / Insert) 3.0 mm (0.12") or 6.0 mm (0.24") Maximum Immersion Length Up to 600 mm (23.62") on request Material (Protection Tube / Thermowell) Stainless steel 1.4404 (316L) Process Connection (Hygienic) • Conical sealing system G1/2" (metal) • Clamp connections ISO 2852 / DIN 32676 • Screwed pipe joint DIN 11851 • Varivent Tip Shape Straight Surface Roughness (Ra) 0.4 µm (16 µin) or 0.8 µm (32 µin) Operating Temperature Range –50 °C to +200 °C (–58 °F to +392 °F) Max. Process Pressure (Static) 100 bar (1,450 psi) at 20 °C Accuracy Class A according to IEC 60751 Response Time t₅₀ = 1 s, t₉₀ = 2 s Head Transmitter Not integrated (requires external 4…20 mA transmitter) Certifications 3-A Sanitary, Marine Approval, UL 3111-1 Summary This compact hygienic RTD sensor delivers fast, precise temperature measurement for sanitary and industrial applications. Built from 316L stainless steel for high durability, it withstands pressures up to 100 bar and operates from –50 °C to +200 °C. The probe can be used directly or with a thermowell and offers multiple hygienic process connection options for easy installation in food, beverage, pharmaceutical, and marine environments.
